push-button

switch.009.006.bis

$51.62

	switch.009.006.bis		OPTION 1	$51.62
	switch.009.006.bis.dimmer		OPTION 2	$77.43

- +

shipped within 1-2 days

ZANGRA SAYS TECHNICAL DESCRIPTION ASSOCIATED PRODUCTS

Technical Information
- 10A, AC 250V
- Rated power of the SBL (self-ballasted lamps) circuit up to 10A: max. 100W.
- Central insert made of porcelain, rocker made of thermoset (Duroplast).

Compatible with flush-mounting box (Ø70mm x 60mm).

OPTION 1: push-button
A push-button is not a normal switch. The electric current is only transmitted when the button is pressed (for example a doorbell).
But if a push-button is used in combination with an impulse relay in the fuse box, then it can be used as a one-way switch, a two-way switch, a timer or a stairwell switch.
And if a push-button is used in combination with home automation then it can be used as a one-way switch, a two-way switch or a stairwell switch, a dimmer, a shutter switch, a doorbell button, a master switch, etc.

General characteristics push-button:

- Compatible with Ø 7 cm flush-mounted boxes.
- Compatible with stairwell impulse relays.
- Compatible with home automation.
- Compatible with a timer.

OPTION 2: push-button with universal regulator
A push-button with a universal regulator becomes a classic switch with dimmer.
This configuration allows you to switch off, switch on and dim a light bulb.
If you install two push-buttons, they will function as two-way switches.
There is no limit to the number of push-buttons that can operate a circuit.

General characteristics push-button with universal regulator:

- This push-button is sold with a built-in regulator, to be placed in a 7 cm Ø flush-mounted box.
- Load for incandescent or halogen bulbs: 4W-250W
- Load for dimmable LED bulbs: 4W-100W
- Light intensity memory. The light varies in intensity when the button is pressed and held for a long time.
